Smart fan
Robust design
High-performance string inverter with proven safety
GoodWe's GT 150kW string inverter is built for large-scale commercial and industrial applications. Prioritizing reliability and safety, this inverter undergoes rigorous testing, ensuring stable performance even in the harshest environments. Its advanced features also simplifies O&M, enhancing efficiency while reducing costs. Powerful, reliable, and smart, the GT Series delivers outstanding performance across all aspects.
21A large input current per string
AI-driven AFCI 3.0 for safety
DC smart circuit breaker
Cost-Effective design
Smart fan
Robust design
Maximised Energy Output
With a 21A large input current per string and 10 MPPTs delivering up to 99.0% efficiency, the GT 150K inverter maximizes power generation even under varying conditions. Easy parallel connection via Ezlink3000 further enhances system scalability and total energy yield.
21A large input current per string
10 MPPTs, max. Efficiency 99.0%
Easy parallel with Ezlink3000
Superb Safety & Reliability
The GT 150K inverter continuously monitors insulation resistance as well as temperature at both AC and DC connectors. When certain thresholds are reached, the DC smart circuit breaker is activated to protect the system. Additionally, the optional AI-driven AFCI 3.0 offers intelligent arc fault detection for enhanced safety.
AI-driven AFCI 3.0 for safety
DC smart circuit breaker
OVERVIEW
Model
GW150K-GT-G10
Max. Input Voltage (V)
1100
Max. Input Current per MPPT (A)
42
Number of MPP trackers/Number of Strings per MPPT
10/2
Max. Efficiency
99.0%
Nominal Output Voltage (V)
220/380, 230/400, 240/415, 3L/N/PE or 3L/PE
